Engineering & Technical Specifications
Slat & Fabric Profiles
Aluminum Slats
- 25mm thick extruded aluminum
- Powder-coated finish with UV protection
- Available in matte, satin, and gloss finishes
- Lightweight yet durable construction
- Corrosion-resistant for humid environments
Wood & Faux-Wood Slats
- 50mm natural basswood or premium faux-wood
- Real wood grain texture with protective coating
- Faux-wood offers moisture resistance for bathrooms/kitchens
- Stainable and paintable options available
- Sustainably sourced materials
Blackout Composite Fabrics
- Flame-retardant, triple-weave composite
- 100% light blackout, with up to 99% UV blocking
- Noise-reducing and thermal insulating properties
- Wipe-clean, mildew-resistant surface
- Available in black, white, and neutral tones
Wood & Faux-Wood Slat Finishes
Nine stock finishes, sampled from our physical finish card. Select one to preview it on the slats.
Finish: Tiger Eye
Headrail & Hardware
Headrail Systems
- Heavy-duty extruded aluminum (1.2mm thickness)
- Concealed mounting brackets for clean appearance
- Reinforced corner joints for structural integrity
- Available in matching finishes to slats/fabrics
- Internal cable routing for motorized systems
Tilt & Lift Mechanisms
- Brass tilt gears for smooth, precise operation
- Stainless steel lift cords with UV protection
- Anti-ratchet systems to prevent slippage
- Low-friction bushings for quiet operation
- Child-safe cord tensioners available
Motorization & Automation
Motor Options
- 24V DC tubular motors (battery/solar compatible)
- 220V AC tubular motors for hardwired installations
- Quiet operation (<44dB) with soft start/stop
- Programmable limits and intermediate positions
- Manual override capability
Smart Home Integration
- RF remote control (433MHz with rolling code)
- Tuya Smart integration (WiFi/Zigbee)
- Amazon Alexa and Google Home voice control
- Apple HomeKit compatibility (via bridge)
- Wall switches and timers available
Performance Specifications
| Specification | Aluminum | Natural Wood | Faux-Wood | Blackout Fabric |
|---|---|---|---|---|
| Material Thickness | 25mm | 50mm | 50mm | 0.45mm (fabric) |
| UV Blocking Rating | 85% (standard) | 75% (natural wood) | 80% (faux-wood) | 99% (blackout) |
| Water Resistance | Excellent | Poor (indoor only) | Excellent | Excellent |
| Fire Rating | Non-combustible | Combustible (treated) | Self-extinguishing | Flame-retardant |
| Temperature Tolerance | -20°C to 80°C | 0°C to 40°C | -10°C to 50°C | -10°C to 60°C |
| Wind Load Resistance | Class 4 (up to 110km/h) | Class 2 (up to 60km/h) | Class 3 (up to 90km/h) | Class 3 (up to 90km/h) |
Wet-Room Suitability
Faux-wood, aluminum, and blackout composite fabric systems are all rated for bathrooms, kitchens, and other high-humidity environments. Natural basswood is recommended for dry, climate-controlled interiors only, as sustained moisture exposure can warp or discolor the timber over time.
